  • 316/316L/316Ti/316H Stainless Steel Pipe/Tube

316/316L/316Ti/316H Stainless Steel Pipe/Tube

  • Product Item : ACE1-1-3
  • Category: Stainless Steel Smls/Weld
  • Grade: 316, 316L, 316Ti, 316H
  • Standard: ASTM, GB, EN, JIS, GOST, DIN
  • Outer Diameter: 10mm - 1000mm
  • Thickness: 0.3-50mm
  • Product description:316 Stainless Steel Pipe, 316L Stainless Steel Tube, 316Ti Stainless Steel Pipe, 316H Stainless Steel Tube
  • INQUIRY   EMAIL

Acewell Industry is one of the top manufacturers and suppliers in 316/316L/316Ti/316H stainless steel pipe/tube. We have more than 20 years of experiences in producing high quality stainless steel and alloy products. We provide the best prices, high quality, good service, and quick delivery time.

Product Details: 316 stainless steel is a molybdenum-alloyed steel. It is the preferred steel for use in marine environments because of its greater resistance to pitting corrosion. Non-standard grades include 316H which has a "high" carbon content of greater than 0.04% giving it a high creep rupture strength at high temperatures, 316L(Hi)N which is an extra-high nitrogen grade (0.16—0.30%), 316Ti which is stabilized by titanium.

Grade
316/316L/316Ti/316H
Standard
ASTM, JIS, AISI, GB, DIN, EN
Outer Diameter
10mm-1000mm
Thickness
0.3-50mm
Length
0.5-12m or as required
Shape
Round, Square, Rectangular
Surface Pickled, Brightened, Annealed, Polished, Colored

Chemical Components


C
Mn P S Si Cr Ni
N
Mo Ti
316
≤0.08
≤2.00
≤0.045
≤0.03
≤0.75
16.0-18.0
10.0-14.0
≤0.10
2.0-3.0

316L
≤0.03
≤2.00
≤0.045
≤0.03
≤0.75
16.0-18.0
10.0-14.0
≤0.10
2.0-3.0

316Ti
≤0.08
≤2.00
≤0.045
≤0.03
≤1.00
16.0-19.0
10.0-14.0

1.8-2.5
0.2-0.7
316H
0.04-0.10
≤2.00
≤0.045
≤0.03
≤0.75
16.0-18.0
10.0-14.0

2.0-3.0

Physical Properties


Tensile Strength (MPA)
Yield Strength (MPA)
Elongation %
Density
316 ≥515
≥205
≥40
7.98
316L ≥485
≥170
≥40
7.98
316Ti ≥520
≥205
≥40
7.98
316H ≥515
≥205
≥40
7.98

Applictaion: 316 stainless steel is commonly used in chemical and petrochemical industry, in food processing, pharmaceutical equipment, medical devices, in potable water, wastewater treatment, in marine applications and architectural applications near the seashore or in urban areas.

Inspection: Strict inspection is from raw materials to finished product. Eddy Current Testing before packaging is must. Unqualified products will be destroyed. Third party inspection is accepted.

Package: Wooven bags, plywood box, wooden box, plastic cap on both ends, or customized. Standard export sea-worthy packaging, inner waterproof paper with outer iron packaging which is fixed on a fumigated woodenpallet. It can effectively protect products from corrosion and various climate changes during ocean transportation.

Certificates: We have ISO, SGS, TUV, BV etc.

Shipping Service: We have self-operated logistics at cost price, and cooperate with overseas agents all over the world to make delivery safely, timely and easily.
