316/316L/316Ti/316H Stainless Steel Sheet/Plate

Product Item : ACE2-1-3
Category： Stainless Steel Sheet
Grade: 316, 316L, 316Ti, 316H
Standard: ASTM, GB, EN, JIS, GOST, DIN
Thickness: Cold rolled:0.2-3.0mm Hot rolled:3.0-60mm
Width: 50-2500mm
Product description：316 Stainless Steel Sheet, 316L Stainless Steel Plate, 316Ti Stainless Steel Sheet, 316H Stainless Steel Plate
INQUIRY EMAIL

Acewell Industry is one of the top manufacturers and suppliers in 316/316L/316Ti/316H stainless steel sheet/plate. We have more than 20 years of experiences in producing high quality stainless steel and alloy products. We provide the best prices, high quality, good service, and quick delivery time.

Product Details: 316 stainless steel is a molybdenum-alloyed steel. It is the preferred steel for use in marine environments because of its greater resistance to pitting corrosion. Non-standard grades include 316H which has a "high" carbon content of greater than 0.04% giving it a high creep rupture strength at high temperatures, 316L(Hi)N which is an extra-high nitrogen grade (0.16—0.30%), 316Ti which is stabilized by titanium.

Grade	316/316L/316Ti/316H
Standard	ASTM, JIS, AISI, GB, DIN, EN
Thickness	Cold rolled:0.2-3.0mm/Hot rolled:3.0-60mm
Width	50-2500mm
Length	1-12m or as required
Surface	No.1, 2B, BA, No.4, Hairline, 8K, Mirror

Chemical Components

	C	Mn	P	S	Si	Cr	Ni	N	Mo	Ti
316	≤0.08	≤2.00	≤0.045	≤0.03	≤0.75	16.0-18.0	10.0-14.0	≤0.10	2.0-3.0
316L	≤0.03	≤2.00	≤0.045	≤0.03	≤0.75	16.0-18.0	10.0-14.0	≤0.10	2.0-3.0
316Ti	≤0.08	≤2.00	≤0.045	≤0.03	≤1.00	16.0-19.0	10.0-14.0		1.8-2.5	0.2-0.7
316H	0.04-0.10	≤2.00	≤0.045	≤0.03	≤0.75	16.0-18.0	10.0-14.0		2.0-3.0

Physical Properties

	Tensile Strength (MPA)	Yield Strength (MPA)	Elongation %	Density
316	≥515	≥205	≥40	7.98
316L	≥485	≥170	≥40	7.98
316Ti	≥520	≥205	≥40	7.98
316H	≥515	≥205	≥40	7.98

Applictaion: 316 stainless steel is commonly used in chemical and petrochemical industry, in food processing, pharmaceutical equipment, medical devices, in potable water, wastewater treatment, in marine applications and architectural applications near the seashore or in urban areas.

Inspection: Strict inspection is from raw materials to finished product. Eddy Current Testing before packaging is must. Unqualified products will be destroyed. Third party inspection is accepted.

Package: Wooven bags, plywood box, wooden box, plastic cap on both ends, or customized. Standard export sea-worthy packaging, inner waterproof paper with outer iron packaging which is fixed on a fumigated woodenpallet. It can effectively protect products from corrosion and various climate changes during ocean transportation.

Certificates: We have ISO, SGS, TUV, BV etc.

Shipping Service: We have self-operated logistics at cost price, and cooperate with overseas agents all over the world to make delivery safely, timely and easily.
